Jansen Steel Window Systems

Arte 2.0 / Arte 66 / Janisol HI / Economy 50

Steel windows combine exceptional stability and durability with slim face widths, allowing for elegant, unobtrusive designs. Schüco Jansen Steel Systems provides a range of solutions, including non-insulated, thermally insulated, and highly thermally insulated systems, catering to diverse architectural styles from classic restorations to contemporary constructions.

  • Narrow face widths thanks to slimline, solid profiles
  • Suitable U values for any application (from non-insulated to highly thermally insulated)
  • Renovation in keeping with the original style, in particular, historical industrial, transport and administration buildings
  • A range of opening types and special geometries are  available, as well as combinations thereof
  • Material to suit every requirement (steel, stainless steel, Corten steel)
  • Robust and secure (burglar and bullet-resistant)
1234/4

Arte 2.0

  • Basic depth 60 mm
  • As a project solution, sash size up to 970 mm × 2970 mm (W × H)
  • Fixed glazing face width 25 mm
  • Faceplate width 60 mm
  • Basic depth 66 mm
  • As a project solution, sash size up to 1160 mm × 3560 mm (W × H)
  • Fixed glazing face width 30 mm
  • Faceplate width 76 mm
  • Basic depth of sash 90 mm, fixed glazing 80 mm
  • Sash size e.g. side-hung and tilt/turn windows up to 1435 mm × 2760 mm (W × H)
  • Frame face width incl. sash 90 mm
  • Faceplate width 110 mm
  • Basic depth 50 mm / 58.5 mm
  • Sash size up to 1475 mm × 2300 mm (W × H)
  • Fixed glazing face width 30 mm
  • Faceplate width 103 mm
